Amazon EKS Anywhere ベアメタルサポートを仮想環境 (VMware ESXi) で検証する

cat /etc/netplan/00-installer-config.yaml
# This is the network config written by 'subiquity'
network:
  ethernets:
    # WAN 側の設定は IPv4 を想定
    # IP アドレスを固定する
    ens33:
      addresses:
        - 192.168.1.200/24
      routes:
        - to: default
          via: 192.168.1.1
      nameservers: # WAN 側のルーターに合わせて設定
        addresses:
          - 192.168.1.1
    # LAN 側の設定
    ens34:
      addresses:
        - 10.8.0.1/16
  version: 2

# コメントアウトを外す
net.ipv4.ip_forward=1

sysctl -p

apt install ufw

ufw allow 22
ufw enable

DEFAULT_FORWARD_POLICY="ACCEPT"

ufw reload

curl "https://github.com/eksctl-io/eksctl/releases/latest/download/eksctl_$(uname -s)_amd64.tar.gz" \
    --silent --location \
    | tar xz -C /tmp
sudo install -m 0755 /tmp/eksctl /usr/local/bin/eksctl

RELEASE_VERSION=$(curl https://anywhere-assets.eks.amazonaws.com/releases/eks-a/manifest.yaml --silent --location | yq ".spec.latestVersion")
EKS_ANYWHERE_TARBALL_URL=$(curl https://anywhere-assets.eks.amazonaws.com/releases/eks-a/manifest.yaml --silent --location | yq ".spec.releases[] | select(.version==\"$RELEASE_VERSION\").eksABinary.$(uname -s | tr A-Z a-z).uri")
curl $EKS_ANYWHERE_TARBALL_URL \
    --silent --location \
    | tar xz ./eksctl-anywhere
sudo install -m 0755 ./eksctl-anywhere /usr/local/bin/eksctl-anywhere

export OS="$(uname -s | tr A-Z a-z)" ARCH=$(test "$(uname -m)" = 'x86_64' && echo 'amd64' || echo 'arm64')
curl -LO "https://dl.k8s.io/release/$(curl -L -s https://dl.k8s.io/release/stable.txt)/bin/${OS}/${ARCH}/kubectl"
sudo install -m 0755 ./kubectl /usr/local/bin/kubectl

export CLUSTER_NAME=expt-eksa-mgmt
eksctl anywhere generate clusterconfig $CLUSTER_NAME --provider tinkerbell > expt-eksa-mgmt-cluster.yaml

apiVersion: anywhere.eks.amazonaws.com/v1alpha1
kind: Cluster
metadata:
  name: expt-eksa-mgmt
spec:
  clusterNetwork:
    cniConfig:
      cilium: {}
    pods:
      cidrBlocks:
      - 10.20.0.0/16
    services:
      cidrBlocks:
      - 10.30.0.0/16
  controlPlaneConfiguration:
    count: 1
    endpoint:
      host: "10.8.10.20"
    machineGroupRef:
      kind: TinkerbellMachineConfig
      name: expt-eksa-mgmt-cp
  datacenterRef:
    kind: TinkerbellDatacenterConfig
    name: expt-eksa-mgmt
  kubernetesVersion: "1.27"
  managementCluster:
    name: expt-eksa-mgmt

---
apiVersion: anywhere.eks.amazonaws.com/v1alpha1
kind: TinkerbellDatacenterConfig
metadata:
  name: expt-eksa-mgmt
spec:
  tinkerbellIP: "10.8.10.10"

---
apiVersion: anywhere.eks.amazonaws.com/v1alpha1
kind: TinkerbellMachineConfig
metadata:
  name: expt-eksa-mgmt-cp
spec:
  hardwareSelector:
    type: cp
  osFamily: bottlerocket
  templateRef: {}
  users:
  - name: ec2-user

eksctl anywhere create cluster --hardware-csv expt-eksa-mgmt-hardware.csv -f expt-eksa-mgmt-cluster.yaml

Warning: The recommended number of control plane nodes is 3 or 5
Warning: No configurations provided for worker node groups, pods will be scheduled on control-plane nodes
Warning: The recommended number of control plane nodes is 3 or 5
Warning: No configurations provided for worker node groups, pods will be scheduled on control-plane nodes
Performing setup and validations
✅ Tinkerbell Provider setup is valid
✅ Validate OS is compatible with registry mirror configuration
✅ Validate certificate for registry mirror
✅ Validate authentication for git provider
✅ Validate cluster's eksaVersion matches EKS-A version
Creating new bootstrap cluster
Provider specific pre-capi-install-setup on bootstrap cluster
Installing cluster-api providers on bootstrap cluster
Provider specific post-setup
Creating new workload cluster

docker logs boots -f

export KUBECONFIG=$(pwd)/${CLUSTER_NAME}/${CLUSTER_NAME}-eks-a-cluster.kubeconfig
kubectl get nodes
