Amazon EC2 I7i Instances
Best Performance, Highest Density Storage Optimized Instances
Why Amazon EC2 I7i Instances?
Amazon EC2 I7i and I7ie instances, powered by 3rd generation AWS Nitro SSDs and 5th generation Intel Xeon Scalable processors with an all-core turbo frequency of 3.2 GHz, offer significant performance improvements for demanding workloads. I7i instances deliver the best compute and storage performance among x86-based Amazon EC2 storage instances, with 23% improved compute performance and more than 10% better price performance compared to previous generation I4i instances. I7ie instances deliver up to 40% improved compute performance and up to 20% better price performance over previous generation I3en instances. Both instance families leverage PCIe Gen5-based AWS Nitro-SSDs, with I7i instances providing up to 45TB of NVMe storage and delivering up to 50% better real-time storage performance, 50% lower storage I/O latency, and 60% reduced I/O latency variability compared to I4i instances. I7ie instances deliver the highest local NVMe storage density in the cloud with up to 120TB of NVMe storage, while delivering up to 65% better real-time storage performance, 50% lower storage I/O latency, and 65% reduced I/O latency variability compared to I3en instances.
I7i and I7ie instances are optimized for storage-intensive workloads that require high-speed access to data residing on local NVMe storage, at real-time latency. The combination of high throughput and low-latency access makes these instances ideal for applications with strict service level agreements (SLAs), including relational databases like MySQL, Oracle DB, and Microsoft SQL Server, as well as NoSQL databases such as MongoDB, Cassandra, Aerospike, Redis, ScyllaDB, Clickhouse, RocksDB. This robust architecture ensures reliable performance for data-intensive applications including real-time analytics (Spark, Kafka, Splunk, Databricks), AI LLM pre-processing for training, distributed file systems, search engines, indexing, and blockchain analysis workloads.
Benefits
High performance secure SSD storage
Built on 3rd generation AWS Nitro SSDs, I7i and I7ie instances deliver industry-leading NVMe storage capacity - up to 45TB for I7i and up to 120TB for I7ie instances, the highest available in the cloud. Both instance families feature always-on AES-256 encryption for enhanced security, and support Torn Write Prevention (TWP), enabling up to 30% better database performance.
Faster application performance
I7i instances optimize transaction processing speeds for highly transactional workloads, enabling higher throughput and helping meet strict application service level agreements (SLAs). This increased performance allows you to deliver faster response times to end-users while processing more transactions per second.
Lower cost for storage intensive workloads
With I7ie instances, you can reduce your cost per GB of SSD instance storage by up to 45% compared to I7i instances, allowing you to better right-size your instance selection based on your specific storage requirements.
Maximized resource efficiency
I7i and I7ie instances are built on the AWS Nitro System, a combination of dedicated hardware and lightweight hypervisor which delivers practically all of the compute and memory resources of the host hardware to your instances for better overall performance and security.
Features
Powered by 5th Generation Intel Xeon Scalable processors
I7i and I7ie instances are powered by 5th generation Intel Xeon Scalable processors (Emerald Rapids) with an all-core turbo frequency of 3.2 GHz (max core turbo frequency of 4.0 GHz), and include support for always-on memory encryption using Intel Total Memory Encryption (TME).
High performance interfaces
I7i and I7ie instances use DDR5 memory, delivering enhanced bandwidth compared to previous generations. These instances support up to 100 Gbps of networking bandwidth and 60 Gbps bandwidth to Amazon Elastic Block Store (EBS). You can attach up to 128 EBS volumes to an instance. Additionally, the 48xlarge and metal-48xl sizes support Elastic Fabric Adapter (EFA) for high-performance computing applications.
New accelerator
5th Generation Intel Xeon Scalable processors feature four built-in accelerators: Advanced Matrix Extensions (AMX) for accelerating CPU-based machine learning through optimized matrix multiplication, Data Streaming Accelerator (DSA), In-Memory Analytics Accelerator (IAA), and QuickAssist Technology (QAT). DSA, IAA, and QAT, exclusively available on I7i and I7ie bare metal instances, optimize performance by efficiently offloading database operations, encryption, compression, and queue management tasks from the CPU.
Product details
I7i instances deliver the best compute and storage performance among x86-based Amazon EC2 storage instances. I7ie instances deliver the highest local NVMe storage density in the cloud.
I7i
Instance Size
|
vCPU
|
Memory (GiB)
|
Instance Storage (GB)
|
Network Bandwidth (Gbps)
|
EBS Bandwidth (Gbps)
|
---|---|---|---|---|---|
i7i.large
|
2
|
16
|
1 x 468 GB = 468 GB
|
Up to 10
|
Up to 10
|
i7i.xlarge
|
4
|
32
|
1 x 937.5 = 937.5 GB
|
Up to 10
|
Up to 10
|
i7i.2xlarge
|
8
|
64
|
1 x 1875 = 1,875 GB
|
Up to 12
|
Up to 10
|
i7i.4xlarge
|
16
|
128
|
1 x 3,750 = 3,750 GB
|
Up to 25
|
Up to 10
|
i7i.8xlarge
|
32
|
256
|
2 x 3,750 = 7,500 GB
|
25 |
10
|
i7i.12xlarge
|
48
|
384
|
3 x 3,750 = 11,250 GB
|
28.125 |
15
|
i7i.16xlarge
|
64
|
512
|
4 x 3,750 = 15,000 GB
|
37.5 |
20
|
i7i.24xlarge
|
96
|
768
|
6 x 3,750 = 22,500 GB
|
56.25 |
30
|
i7i.48xlarge
|
192
|
1536
|
12 x 3,750 = 45,000 GB
|
100 |
60
|
i7i.metal-24xl
|
96
|
768
|
6 x 3,750 = 22,500 GB
|
56.25 |
30
|
i7i.metal-48xl
|
192
|
1,536
|
12 x 3,750 = 45,000 GB
|
100 |
60
|
i7ie
Instance Size
|
vCPU
|
Memory (GiB)
|
Instance Storage (GB)
|
Network Bandwidth (Gbps)
|
EBS Bandwidth (Gbps)
|
---|---|---|---|---|---|
i7ie.large
|
2
|
16
|
1 x 1,250 GB = 1,250 GB
|
Up to 25
|
Up to 10
|
i7ie.xlarge
|
4
|
32
|
1 x 2,500 GB = 2,500 GB
|
Up to 25
|
Up to 10
|
i7ie.2xlarge
|
8
|
64
|
2 x 2,500 GB = 5,000 GB
|
Up to 25
|
Up to 10
|
i7ie.3xlarge
|
12
|
96
|
1 x 7,500 GB = 7,500 GB
|
Up to 25
|
Up to 10
|
i7ie.6xlarge
|
24
|
192
|
2 x 7,500 GB = 15,000 GB
|
Up to 25 |
10 |
i7ie.12xlarge
|
48
|
384
|
4 x 7,500 GB = 30,000 GB
|
Up to 50 |
15
|
i7ie.18xlarge
|
72
|
576
|
6 x 7,500 GB = 45,000 GB
|
Up to 75 |
22.5
|
i7ie.24xlarge
|
96
|
768
|
8 x 7,500 GB = 60,000 GB
|
Up to 100 |
30
|
i7ie.48xlarge
|
192
|
1,536
|
16 x 7,500 GB = 120,000 GB
|
100 |
60
|
i7ie.metal-24xl
|
96
|
768
|
8 x 7,500 GB = 60,000 GB
|
Up to 100 |
30
|
i7ie.metal-48xl
|
192
|
1,536
|
16 x 7,500 GB = 120,000 GB
|
100 |
60
|
