Amazon OpenSearch Ingestion 101: Set CloudWatch alarms for key metrics

Amazon OpenSearch Ingestion is a fully managed, serverless data pipeline that simplifies the process of ingesting data into Amazon OpenSearch Service and OpenSearch Serverless collections. Some key concepts include:

• Source – Input component that specifies how the pipeline ingests the data. Each pipeline has a single source which can be either push-based and pull-based.
• Processors – Intermediate processing units that can filter, transform, and enrich records before delivery.
• Sink – Output component that specifies the destination(s) to which the pipeline publishes data. It can publish records to one or more destinations.
• Buffer – It is the layer between the source and the sink. It serves as temporary storage for events, decoupling the source from the downstream processors and sinks. Amazon OpenSearch Ingestion also offers a persistent buffer option for push-based sources
• Dead-letter queues (DLQs) – Configures Amazon Simple Storage Service (Amazon S3) to capture records that fail to write to the sink, enabling error handling and troubleshooting.

This end-to-end data ingestion service can help you collect, process, and deliver data to your OpenSearch environments without the need to manage underlying infrastructure.

This post provides an in-depth look at setting up Amazon CloudWatch alarms for OpenSearch Ingestion pipelines. It goes beyond our recommended alarms to help identify bottlenecks in the pipeline, whether that’s in the sink, the OpenSearch clusters data is being sent to, the processors, or the pipeline not pulling or accepting enough from the source. This post will help you proactively monitor and troubleshoot your OpenSearch Ingestion pipelines.

Overview

Monitoring your OpenSearch Ingestion pipelines is crucial for catching and addressing issues early. By understanding the key metrics and setting up the right alarms, you can proactively manage the health and performance of your data ingestion workflows. In the following sections, we provide details about alarm metrics for different sources, monitors, and sinks. The specific values for the threshold, period, and datapoints to alarm used for alarms can vary based on the individual use case and requirements.

Prerequisites

To create an OpenSearch Ingestion pipeline, refer to Creating Amazon OpenSearch Ingestion pipelines. For creating CloudWatch alarms, refer to Create a CloudWatch alarm based on a static threshold.

You can enable logging for OpenSearch Ingestion Pipeline, which captures various log messages during pipeline operations and ingestion activity, including errors, warnings, and informational messages. For details on enabling and monitoring pipeline logs, refer to Monitoring pipeline logs

Sources

The entry point of your pipeline is often where monitoring should begin. By setting appropriate alarms for source components, you can quickly identify ingestion bottlenecks or connection issues. The following table summarizes key alarm metrics for different sources.

Processors

The following table provides details about alarm metrics for different processors.

Sinks and DLQs

The following table contains details about alarm metrics for different sinks and DLQs.

Buffer

The following table contains details about alarm metrics for buffers.

Reference Guide

The following provide guidance for resolving common pipeline issues along with general reference.

REF-001: WARN-level Log Review

Review WARN-level logs in the pipeline logs to identify the exception details.

REF-002: ERROR-level Log Review

Review ERROR-level logs in the pipeline logs to identify the exception details.

REF-003: S3 Objects Failed

When troubleshooting increasing s3ObjectsFailed.count values, monitor these specific metrics to narrow down the root cause:

• s3ObjectsAccessDenied.count – This metric increments when the pipeline encounters Access Denied or Forbidden errors while reading S3 objects. Common causes include:
• Insufficient permissions in the pipeline role.
• Restrictive S3 bucket policy not allowing the pipeline role access.
• For cross-account S3 buckets, incorrectly configured bucket_owners mapping.
• s3ObjectsNotFound.count – This metric increments when the pipeline receives Not Found errors while attempting to read S3 objects.

For further assistance with the recommended actions, contact AWS support.

REF-004: Configuring Alarm for difference in totalOpenShards.max and activeShardsInProcessing.value for Amazon DynamoDB source.

1. Open the CloudWatch console at https://console.aws.amazon.com/cloudwatch/.
2. In the navigation pane, choose Alarms, All alarms.
3. Choose Create alarm.
4. Choose Select Metric.
5. Select Source.
6. In source, following JSON can be used after updating the <sub-pipeline-name>, <pipeline-name> and <region>.

   {
       "metrics": [
           [ { "expression": "m1-e1", "label": "Expression2", "id": "e2", "period": 900 } ],
           [ { "expression": "FLOOR((m2/15)+0.5)", "label": "Expression1", "id": "activeShardsInProcessing", "visible": false, "period": 900 } ],
           [ "AWS/OSIS", "<sub-pipeline-name>.dynamodb.totalOpenShards.max", "PipelineName", "<pipeline-name>", { "stat": "Maximum", "id": "m1", "visible": false } ],
           [ ".", "<sub-pipeline name>.dynamodb.activeShardsInProcessing.value", ".", ".", { "stat": "Average", "id": "m2", "visible": false } ]
       ],
       "view": "timeSeries",
       "stacked": false,
       "period": 900,
       "region": "<region>"
   }

Let’s review couple of scenarios based on the above metrics.

Scenario 1 – Understand and Lower Pipeline Latency

Latency within a pipeline is built up of three main components:

• The time it takes to send documents via bulk requests to OpenSearch,
• the time it takes for data to go through the pipeline processors, and
• the time that data sits in the pipeline buffer

Bulk requests and processors (last two items in the previous list) are the root causes for why the buffer builds up and leads to latency.

To monitor how much data is being stored in the buffer, monitor the bufferUsage.value metric. The only way to lower latency within the buffer is to optimize the pipeline processors and sink bulk request latency, depending on which of those is the bottleneck.

The bulkRequestLatency metric measures the time taken to execute bulk requests, including retries, and can be used to monitor write performance to the OpenSearch sink. If this metric reports an unusually high value, it indicates that the OpenSearch sink may be overloaded, causing increased processing time. To troubleshoot further, review the bulkRequestNumberOfRetries.count metric to confirm whether the high latency is due to rejections from OpenSearch that are leading to retries, such as throttling (429 errors) or other reasons. If document errors are present, examine the configured DLQ to identify the failed document details. Additionally, the max_retries parameter can be configured in the pipeline configuration to limit the number of retries. However, if the documentErrors metric reports zero, the bulkRequestNumberOfRetries.count is also zero, and the bulkRequestLatency remains high, it is likely an indicator that the OpenSearch sink is overloaded. In this case, review the destination metrics for additional details.

If the bulkRequestLatency metric is low (for example, less than 1.5 seconds) and the bulkRequestNumberOfRetries metric is reported as 0, then the bottleneck is likely within the pipeline processors. To monitor the performance of the processors, review the <processorName>.timeElapsed.avg metric. This metric reports the time taken for the processor to complete processing of a batch of records. For example, if a grok processor is reporting a much higher value than other processors for timeElapsed, it may be due to a slow grok pattern that can be optimized or even replaced with a more performant processor, depending on the use case.

Scenario 2 – Understanding and Resolving Document Errors to OpenSearch

The documentErrors.count metric tracks the number of documents that failed to be sent by bulk requests. The failure can happen due to various reasons such as mapping conflicts, invalid data formats, or schema mismatches. When this metric reports a non-zero value, it indicates that some documents are being rejected by OpenSearch. To identify the root cause, examine the configured Dead Letter Queue (DLQ), which captures the failed documents along with error details. The DLQ provides information about why specific documents failed, enabling you to identify patterns such as incorrect field types, missing required fields, or data that exceeds size limits. For example, find the sample DLQ objects for common issues below:

Mapper parsing exception:

{"dlqObjects": [{
        "pluginId": "opensearch",
        "pluginName": "opensearch",
        "pipelineName": "<PipelineName>",
        "failedData": {
            "index": "<IndexName>",
            "indexId": null,
            "status": 400,
            "message": "failed to parse field [<fieldname>] of type [integer] in document with id '<DocumentId>'. Preview of field's value: 'N/A' caused by For input string: \"N/A\"",
            "document": {<OriginalDocument>}
        },
        "timestamp": "…"
    }]}

Here, OpenSearch cannot store the text string “N/A” in a field that is only for numbers, so it rejects the document and stores it in the DLQ.

Limit of total fields exceeded:

{"dlqObjects": [{
        "pluginId": "opensearch",
        "pluginName": "opensearch",
        "pipelineName": "<PipelineName>",
        "failedData": {
            "index": "<IndexName>",
            "indexId": null,
            "status": 400,
            "message": "Limit of total fields [<field limit>] has been exceeded",
            "document": {<OriginalDocument>}
        },
        "timestamp": "…"
    }]}

The index.mapping.total_fields.limit setting is the parameter that controls the maximum number of fields allowed in an index mapping, and exceeding this limit will cause indexing operations to fail. You can check if all those fields are required or leverage various processors provided by OpenSearch Ingestion to transform the data.

Once these issues are identified, you can either correct the source data, adjust the pipeline configuration to transform the data appropriately, or modify the OpenSearch index mapping to accommodate the incoming data format.

Clean up

When setting up alarms for monitoring your OpenSearch Ingestion pipelines, it’s important to be mindful of the potential costs involved. Each alarm you configure will incur charges based on the CloudWatch pricing model.

To avoid unnecessary expenses, we recommend carefully evaluating your alarm requirements and configuring them accordingly. Only set up the alarms that are essential for your use case, and regularly review your alarm configurations to identify and remove unused or redundant alarms.

Conclusion

In this post, we explored the comprehensive monitoring capabilities for OpenSearch Ingestion pipelines through CloudWatch alarms, covering key metrics across various sources, processors, and sinks. Although this post highlights the most critical metrics, there’s more to discover. For a deeper dive, refer to the following resources:

• Recommended CloudWatch alarms
• Supported plugins and options for Amazon OpenSearch Ingestion pipelines
• Monitoring pipeline metrics

Effective monitoring through CloudWatch alarms is crucial for maintaining healthy ingestion pipelines and maintaining optimal data flow.
