AWS cloud provides a broadest range of scalable, flexible infrastructure services that you can select to match your workloads and tasks. This gives you the ability to choose the most appropriate mix of resources for your specific applications. Cloud computing makes it easy to experiment with infrastructure components and architecture design. The services listed below as HPC solution components are a great starting point to set up and manage your HPC cluster, however, we always recommend testing various instance types, EBS volume types, deployment methods, etc., to find the best performance at the lowest cost.
Data Management & Data Transfer
Running HPC applications in the cloud starts with moving the required data into the cloud. AWS Snowball and AWS Snowmobile are data transport solutions that use devices designed to be secure to transfer large amounts of data into and out of the AWS Cloud. Using Snowball addresses common challenges with large-scale data transfers including high network costs, long transfer times, and security concerns. AWS DataSync is a data transfer service that makes it easy for you to automate moving data between on-premises storage and Amazon S3 or Amazon Elastic File System (Amazon EFS). DataSync automatically handles many of the tasks related to data transfers that can slow down migrations or burden your IT operations, including running your own instances, handling encryption, managing scripts, network optimization, and data integrity validation. AWS Direct Connect is a cloud service solution that makes it easy to establish a dedicated network connection from your premises to AWS. Using AWS Direct Connect, you can establish private connectivity between AWS and your datacenter, office, or colocation environment, which in many cases can reduce your network costs, increase bandwidth throughput, and provide a more consistent network experience than Internet-based connections.
Compute & Networking
Compute: The AWS HPC solution lets you choose from a variety of compute instance types that can be configured to suit your needs, including the latest Intel® Xeon® processor-powered CPU instances, GPU-based instances, and field programmable gate array (FPGA)-powered instances. The latest Intel- powered Amazon EC2 instances include the C5n, C5d and Z1d instances. C5n instances feature the Intel Xeon Platinum 8000 series (Skylake-SP) processor with a sustained all core Turbo CPU clock speed of up to 3.5 GHz. C5n instances provide up to 100 Gbps of network bandwidth and up to 14 Gbps of dedicated bandwidth to Amazon EBS. C5n instances also feature 33% higher memory footprint compared to C5 instances. For workloads that require access to high-speed, ultra-low latency local storage, AWS offers C5d instances equipped with local NVMe-based SSDs. Amazon EC2 z1d instances offer both high compute capacity and a high memory footprint. High frequency z1d instances deliver a sustained all core frequency of up to 4.0 GHz, the fastest of any cloud instance. For HPC codes that can benefit from GPU acceleration, the Amazon EC2 P3dn instances feature 100 Gbps network bandwidth (up to 4x the bandwidth of previous P3 instances), local NVMe storage, the latest NVIDIA V100 Tensor Core GPUs with 32 GB of GPU memory, NVIDIA NVLink for faster GPU-to-GPU communication, AWS-custom Intel® Xeon® Scalable (Skylake) processors running at 3.1 GHz sustained all-core Turbo. AWS Auto Scaling monitors your applications and automatically adjusts capacity to maintain steady, predictable performance at the lowest possible cost. Using AWS Auto Scaling, it’s easy to setup application scaling for multiple resources across multiple services in minutes.
Networking: Amazon EC2 instances support enhanced networking that allow EC2 instances to achieve higher bandwidth and lower inter-instance latency compared to traditional virtualization methods. Elastic Fabric Adapter (EFA) is a network interface for Amazon EC2 instances that enables you to run HPC applications requiring high levels of inter-node communications at scale on AWS. Its custom-built operating system (OS) bypass hardware interface enhances the performance of inter-instance communications, which is critical to scaling HPC applications. AWS also offers placement groups for tightly-coupled HPC applications that require low latency networking. Amazon Virtual Private Cloud (VPC) provides IP connectivity between compute instances and storage components.
Storage options and storage costs are critical factors when considering an HPC solution. AWS offers flexible object, block, or file storage for your transient and permanent storage requirements. Amazon Elastic Block Store (Amazon EBS) provides persistent block storage volumes for use with Amazon EC2. Provisioned IOPS allows you to allocate storage volumes of the size you need and to attach these virtual volumes to your EC2 instances. Amazon Simple Storage Service (S3) is designed to store and access any type of data over the Internet and can be used to store the HPC input and output data long term and without ever having to do a data migration project again. Amazon FSx for Lustre is a high performance file storage service designed for demanding HPC workloads and can be used on Amazon EC2 in the AWS cloud. Amazon FSx for Lustre works natively with Amazon S3, making it easy for you to process cloud data sets with high performance file systems. When linked to an S3 bucket, an FSx for Lustre file system transparently presents S3 objects as files and allows you to write results back to S3. You can also use FSx for Lustre as a standalone high-performance file system to burst your workloads from on-premises to the cloud. By copying on-premises data to an FSx for Lustre file system, you can make that data available for fast processing by compute instances running on AWS. Amazon Elastic File System (Amazon EFS) provides simple, scalable file storage for use with Amazon EC2 instances in the AWS Cloud.
Automation and Orchestration
Automating the job submission process and scheduling submitted jobs according to predetermined policies and priorities are essential for efficient use of the underlying HPC infrastructure. AWS Batch lets you run hundreds to thousands of batch computing jobs by dynamically provisioning the right type and quantity of compute resources based on the job requirements. AWS ParallelCluster is a fully supported and maintained open source cluster management tool that makes it easy for scientists, researchers, and IT administrators to deploy and manage High Performance Computing (HPC) clusters in the AWS Cloud. NICE EnginFrame is a web portal designed to provide efficient access to HPC-enabled infrastructure using a standard browser. EnginFrame provides you a user-friendly HPC job submission, job control, and job monitoring environment.
Operations & Management
Monitoring the infrastructure and avoiding cost overruns are two of the most important capabilities that can help an HPC system administrators efficiently manage your organization’s HPC needs. Amazon CloudWatch is a monitoring and management service built for developers, system operators, site reliability engineers (SRE), and IT managers. CloudWatch provides you with data and actionable insights to monitor your applications, understand and respond to system-wide performance changes, optimize resource utilization, and get a unified view of operational health. AWS Budgets gives you the ability to set custom budgets that alert you when your costs or usage exceed (or are forecasted to exceed) your budgeted amount.
The ability to visualize results of engineering simulations without having to move massive amounts of data to/from the cloud is an important aspect of the HPC stack. Remote visualization helps accelerate the turnaround times for engineering design significantly. NICE DCV enables you to remotely access 2D/3D interactive applications over a standard network. In addition, Amazon AppStream 2.0 is another fully managed application streaming service that can securely deliver application sessions to a browser on any computer or workstation.
Security and Compliance
Security management and regulatory compliance are other important aspects of running HPC in the cloud. AWS offers multiple security related services and quick-launch templates to simplify the process of creating a HPC cluster and implementing best practices in data security and regulatory compliance. The AWS infrastructure puts strong safeguards in place to help protect customer privacy. All data is stored in highly secure AWS data centers. AWS Identity and Access Management (IAM) provides a robust solution for managing users, roles, and groups that have rights to access specific data sources. Organizations can issue users and systems individual identities and credentials, or provision them with temporary access credentials using the Amazon Security Token Service (Amazon STS). AWS manages dozens of compliance programs in its infrastructure. This means that segments of your compliance have already been completed. AWS infrastructure is compliant with many relevant industry regulations such as HIPAA, FISMA, FedRAMP, PCI, ISO 27001, SOC 1, and others.
