Cisco Cloud Services Router (CSR) 1000V - Security Pkg. Max Performance

30 Day Free Trial Available - The Security Technology Package for Maximum Performance version of Cisco Cloud Services Router (CSR1000V) delivers the maximum VPN/firewall performance in the AWS cloud, by using AWS instances with direct I/O path for higher & more consistent IPSec performance & 2x the IPSec performance with IMIX packets. The CSR1000V is a full Cisco IOS-XE router (i.e. ASR1K) in an AMI form factor that enables AWS customers to easily extend their enterprise security policies to AWS cloud in point-to-point or point-to-multipoint deployments. With CSR1000V, AWS customers can deploy enterprise-class... Read more


    Customer Rating

    (0 Customer Reviews)
    0 review
    5 star:

    (0)
    4 star:

    (0)
    3 star:

    (0)
    2 star:

    (0)
    1 star:

    (0)

    Latest Version

    16.6.1 (Other available versions)


    Operating System

    Linux/Unix, Other Cisco IOS XE


    Delivery Methods

      • Single AMI
      • 64-bit Amazon Machine Image (AMI) (Learn more)
      • Single box deployment of the product
      • Cisco CSR 1000V - Security Pkg. Max Performance
      • CloudFormation Template (View)
      • Cisco Cloud Services Router (CSR) 1000V - Security Pkg. Max Performance


    AWS Services Required

    Amazon EC2, Amazon EBS


    Highlights

    • Enterprise-class VPN in AWS that's faster, cheaper, and more scalable than other VPN solutions. Manage both sides of your VPN for greater security. Familiar IOS-XE based VPN supports the same commands, tools, and logs as Cisco ISR and ASR platforms.
    • More secure, reliable, and cost effective than native VPN. Feature-rich: IPSec, DMVPN, FlexVPN, GETVPN, EZVPN, SSL VPN, Zone-Based Firewall, and more...
    • IPSec performance Guide: t2.medium for up to 250 Mbps. c4.large for up to 500 Mbps. c4.xlarge for 1 Gbps. c3.2xlarge for up to 1Gbps, c4.2xlarge for up to 2.5 Gbps and c4.4xlarge for up to 4.5Gbps

    Product Description

    The Security Technology Package for Maximum Performance version of Cisco Cloud Services Router (CSR1000V) delivers the maximum VPN/firewall performance in the AWS cloud, by using AWS instances with direct I/O path for higher & more consistent IPSec performance & 2x the IPSec performance with IMIX packets. The CSR1000V is a full Cisco IOS-XE router (i.e. ASR1K) in an AMI form factor that enables AWS customers to easily extend their enterprise security policies to AWS cloud in point-to-point or point-to-multipoint deployments. With CSR1000V, AWS customers can deploy enterprise-class VPN 3x times faster than with native or other VPN solutions, and they can control and manage both sides of the VPN tunnel for higher security. Unlike native VPN, CSR provides notifications, logs and debugging commands and terminates many VPN tunnels with one instance. Native VPN solutions only offer site-to-site IPSec, but the CSR1000V offers IPSec, DMVPN, GETVPN, FLEXVPN, SSL VPN, and VTI-VPN: static and dynamic. It also offers advanced config options: pre-shared key, certificates (PKI), SHA-1 &2, DES, 3DES, AES-128, 192, 256, & 512, DH Groups 1-24, and ECP in addition to MODP 2 & 5, ike-v1 & v2. It also includes enterprise-class Zone Based Firewall and routing functionality: BGP, OSPF, EIGRP, RIP, ISIS, IPv6, GRE, VRF-LITE, NTP, QoS, 802.1Q VLAN, EVC, NAT, DHCP, DNS, ACL, AAA, RADIUS, TACACS+, IOS-XE CLI, SSH, Flexible NetFlow, SNMP, EEM, and NETCONF

    Product Details

    • Version: 16.6.1
    • Available on AWS Marketplace Since: 04/28/2015

    Annual Subscription Details

    Annual software subscription requires one time up front payment with no ongoing charges, and covers all software fees for the selected instance type. Hourly AWS infrastructure usage fees still apply. Learn more about annual subscriptions

    Resources

    Usage Instructions

    Complete the following steps to launch a CSR 1000V AMI:1. Locate the CSR 1000V product page by searching the AWS Marketplace for "CSR 1000V".2. On the CSR 1000V product page, click the "Continue"...

    Read more

    Support Details

    Cisco Cloud Services Router (CSR) 1000V - Security Pkg. Max Performance

    Cisco TAC support services for CSR SEC LicenseIncluded is available for purchase through partners listed. Match your CSR instance type to the throughput support coverage you require
    SEC
    t2.medium 250Mbps
    m3.medium 250Mbps
    c4.large 500Mbps
    c4.xlarge 1000Mbps
    C3.2xlarge 1000Mbps
    c4.2xlarge 2500Mbps
    c4.4xlarge 5000Mbps
    c4.8xlarge 5000Mbps

    Support Community: https://supportforums.cisco.com/community/csr-amazon .
    This listing includes a 60-day free trail period for first-time users.
    To set up CSR, watch https://www.youtube.com/watch?v=CkAeG0bBEcc
    To test CSR in a free lab, visit www.csrtestdrive.com
    For questions and to obtain CSR1000V AMI access to the GovCloud region, contact ask-csr-aws-pm@cisco.com

    http://www.groupwaretech.com/awsmarketplace/cisco/
    WWW.TRACE3.COM
    WWW.SHI.COM
    WWW.SYCOMP.COM
    WWW.COMPUTACENTER.COM (EMEAR)
    WWW.VELOCIS.IN

    AWS Infrastructure

    AWS Support is a one-on-one, fast-response support channel that is staffed 24x7x365 with experienced and technical support engineers. The service helps customers of all sizes and technical abilities to successfully utilize the products and features provided by Amazon Web Services. Learn more

    Refund Policy

    CSR1000V can be cancelled at any time. Customers will only be billed for time and transfer that is actually used while an AWS instance running CSR1000V is active

    Annual Subscriptions:

    Annual subscription cancellations or downgrades are not supported. If you need help with or want to upgrade your subscriptions, please click here

    End User License Agreement

    By subscribing to this product you agree to terms and conditions outlined in the product End User License Agreement (EULA).
