Overview
The Juniper Cloud-Native Router (JCNR) is a container-based software solution that combines the JCNR-controller (cRPD-based control plane) and the JCNR vRouter (DPDK-enabled forwarding/data plane). With the cloud-native router, you can enable Junos OS-based switching control with enhanced forwarding capabilities.
The JCNR controller, running on a Kubernetes (K8s) compute host, provides control plane management functionality and uses the forwarding capabilities provided by either the Linux kernel or the DPDK-enabled JCNR vRouter.
DPDK is an open source set of libraries and drivers. It enables fast packet processing by allowing network interface cards (NICs) to send direct memory access (DMA) packets directly into an application's address space. The applications poll for packets to avoid the overhead of interrupts from the NIC. integrating the DPDK allows a vRouter to process more packets per second than is possible when the vRouter runs as a kernel module.
In this integrated solution, the JCNR Controller uses gPRC-based services to exchange messages and to communicate with the JCNR vRouter, thus creating a fully functional Cloud Native Router.
This close communication allows you to: -Learn about fabric and workload interfaces -Provision DPDK or kernel-based interfaces for K8s pods as needed -Configure IPv4 and IPv6 address allocation for Pods. Furthermore, it incorporates a versatile Virtual Private Cloud (VPC) Gateway feature that's ideally suited for both enterprise and telecom networks.
Highlights
- Advanced Service Integration. Easily integrate cloud-native, advanced Junos OS networking services into cloud applications, accelerating development and increasing reliability. The router is designed to support service providers with Layer-3 VPNs, MPLS, dynamic service configuration, fault detection, high-availability configurations, dynamic routing protocols, and more.
- Fast Packet Processing. Cloud-Native Router includes an integrated, high-performance Contrail DPDK forwarding plane, which is industry proven and hardened for reliable performance.
- Deployment Simplicity. Implemented in Kubernetes, Cloud-Native Router meets deployment and management needs, working on both Operations 1.0 and 2.0 environments. Operations 1.0 using Junos OS CLI or Network Configuration Protocol (NETCONF). Operations 2.0 using Kubernetes Manifest or Terraform
Details
Features and programs
Quick Launch
Pricing
Vendor refund policy
We do not currently support refunds, but you can cancel at any time.
Legal
Vendor terms and conditions
Content disclaimer
Delivery details
Juniper Cloud-Native Router (BYOL) - HELM
- Amazon EKS
Helm chart
Helm charts are Kubernetes YAML manifests combined into a single package that can be installed on Kubernetes clusters. The containerized application is deployed on a cluster by running a single Helm install command to install the seller-provided Helm chart.
Additional details
Usage instructions
Configure AWS credentials using
aws configure
Authenticate to ECR repo aws ecr get-login-password --region us-east-1 | docker login --username AWS --password-stdin 709825985650.dkr.ecr.us-east-1.amazonaws.com
Download the helm from ECR repo helm pull oci://709825985650.dkr.ecr.us-east-1.amazonaws.com/juniper-networks/jcnr --version 24.2.0-354
The above command will download the jcnr helm package jcnr-24.2.0-354.tgz
Once the package is downloaded the user should follow the instructions provided in the below JCNR document
