Jump-Start Your EDA Chip Design, Verification, and Implementation The Cadence Managed Cloud Service is an EDA-optimized platform that provides a fully integrated and proven cloud environment to jump-start product design, verification, and implementation. The platform serves a full front-to-back design flow and a, partial design flow, as well as hybrid cloud-based peak capacity (leveraging Amazon EC2, S3, and other AWS services).
As semiconductor and system design becomes increasingly intricate, the compute needs of design teams grow exponentially. The limitations of traditional on-prem datacenters—capacity restrictions, inconsistent turnaround times, and upfront CapEx investment—hinder engineering productivity, project deadlines, cost-efficiency, and ultimately time to market. Working in the cloud removes these limitations, but requires unique IT and EDA expertise is needed to set up and manage an efficient public cloud environment. The Cadence Managed Cloud Service remove these barriers and get your project up and running in a matter of days.
Highlights
- Quick Ramp-Up Ready-to-use cloud environment and pre-installed tools and licenses and Cost-Efficient Scaling of compute and infrastructure capacity to match workload changes
- EDA-Optimized Environment enables front-to-back design flow and tool-specific peak demands Push-Button Cloud Scalability.
- ISO Security-Certified. Meet advanced foundry requirements.
Details
Introducing multi-product solutions
You can now purchase comprehensive solutions tailored to use cases and industries.
