Overview
CacheGuard Gateway is a network Security and traffic Optimization appliance that you can implement easily and quickly in your organization. When you deploy a CacheGuard Gateway, you get multiple features in a single box and it's up to you to activate features as per your requirements.
You can use CacheGuard Gateway either as a forwarding proxy to get security while browsing the Web or as a reverse proxy to protect your Web applications on the cloud. As a forwarding proxy, CacheGuard Gateway filters unwanted websites and block malware even before they can enter into your networks. As a reverse proxy, CacheGuard Gateway acts as a WAF (Web Application Firewall) and allows you to protect your applications against content attacks. In addition, CacheGuard Gateway comes with a VPN server, a Web application load balancer, a Firewall, a Web caching system, a traffic shaping and QoS facility, a mini PKI and much more. CacheGuard Gateway gives you the power to do it all as easily as possible.
The PAYG license type comes with the Standard Support and UBL & EAV (URL Blacklists & Extended Antivirus) services. Please note that in order to register your appliance and receive your credentials to access UBL & EAV services, you will be asked to provide a contact name and a valid e-mail address during the deployment.
Highlights
- Quick & Easy to Handle
- Mature & Powerful but at a Fair Price
- All in One UTM (Unified Threat Management)
Details
Features and programs
Financing for AWS Marketplace purchases
Pricing
Instance type | Product cost/hour | EC2 cost/hour | Total/hour |
|---|---|---|---|
c5.2xlarge | $0.04 | $0.34 | $0.38 |
c5d.2xlarge | $0.04 | $0.384 | $0.424 |
c5a.2xlarge | $0.04 | $0.308 | $0.348 |
c5ad.2xlarge | $0.04 | $0.344 | $0.384 |
c6i.2xlarge | $0.04 | $0.34 | $0.38 |
c6a.2xlarge | $0.04 | $0.306 | $0.346 |
Vendor refund policy
Terminate your CacheGuard Gateway EC2 instance or delete your CacheGuard Gateway CloudFormation Stack to stop paying CacheGuard Gateway usage.
Legal
Vendor terms and conditions
Content disclaimer
Delivery details
CacheGuard Gateway F100-R20 (PAYG)
The CFT (Cloud Formation Template) allows you to properly deploy a CacheGuard Gateway on AWS cloud. It is important to note that without the usage of the CFT, CacheGuard Gateway would not work.
To work, a CacheGuard Gateway requires at least 2 NIC (Network Interface Card). The two NIC are the internal and the external NIC. Protected users and Web applications should be placed behind the internal NIC (trusted zone) while the external NIC allows the Gateway to communicate with the untrusted internet. The CFT creates the two required network interfaces, connect them to two distinct sub networks and assigns to each NIC a private and a public IP address. The internal public IP address can be freed if end-users of the CacheGuard Web proxy do not need to directly connect to the Gateway via the internet (but connect using CacheGuard VPN).
All AWS resources are created in a dedicated VPC by default. The created EC2 instance on which CacheGuard Gateway run can then be moved to other VPC and/or networks according to your infrastructure architecture on AWS.
CloudFormation Template (CFT)
AWS CloudFormation templates are JSON or YAML-formatted text files that simplify provisioning and management on AWS. The templates describe the service or application architecture you want to deploy, and AWS CloudFormation uses those templates to provision and configure the required services (such as Amazon EC2 instances or Amazon RDS DB instances). The deployed application and associated resources are called a "stack."
Version release notes
Additional details
Usage instructions
You can manage your CacheGuard Gateway via its Web GUI at https://<cacheguard-public-ip>:8090 or via SSH. By default, CacheGuard Gateway on AWS uses two distinct public IP addresses: one external public IP used for outgoing traffic to the internet and one internal public IP used for incoming connections to its embedded Web proxy on the TCP port 8080. If from the same local public IP address you manage AND use your CacheGuard Gateway (as a Web proxy), your CacheGuard Gateway will be accessible only on its internal public IP address from that local public IP address.
CacheGuard Gateway is provided with full online and offline documentation that include a User’s Guide and a Command Line Manual. You can find the CacheGuard Documentation via CacheGuard administration interfaces (Console, SSH and HTTPS) or online on the Web.
You can monitor the health of a CacheGuard Gateway either by inspecting the reports that are made available via its Web GUI or by using the “system report” command line. In addition, CacheGuard Gateway supports SNMP and the syslog protocol.
CacheGuard Gateway on AWS requires that you provide a contact name and a valid email address in order to register your appliance and allow you to benefit from our services Please refer to the CacheGuard Privacy Policy for more details at https://www.cacheguard.net/pdf/CacheGuard-Privacy-Policy.pdf .
Resources
Vendor resources
Support
Vendor support
With the PAYG license type you benefit from the Standard Support level. The Standard Support level allows you to have direct access to CacheGuard experts in order to resolve any issues you may have with CacheGuard products. In addition, you benefit from a collaborative help portal to find an answer to your technical questions.
AWS infrastructure support
AWS Support is a one-on-one, fast-response support channel that is staffed 24x7x365 with experienced and technical support engineers. The service helps customers of all sizes and technical abilities to successfully utilize the products and features provided by Amazon Web Services.
