Overview
BeVyPN Network Architecture
BeVyPN Network Architecture
BeVyPN Subscriber Creation screenshot
BeVyPN Subscriber On Boarding workflow
BeVyPN Subscribers Management screenshot
BeVyPN allows you to own and manage your own dedicated VPN and this without having any network and security knowledge. With BeVyPN, you setup your VPN service and connect the persons of your choice in record time.
Once connected via BeVyPN to the internet, end users benefit not only from a powerful and highly secured VPN but also from a Proxy and a Firewall. In addition, with BeVyPN you get QoS (Quality of Service) for your network traffic.
With BeVyPN, you simply ask the application to create VPN accounts. The application records your requests and creates the VPN accounts for you in the background. Once the VPN accounts have been created, you download the associated VPN profiles and send them to your subscribers by email. BeVyPN can also be configured to automatically email the VPN profiles on your behalf. Finally, you send the passwords protecting the VPN profiles to your subscribers via your preferred messaging App.
First connection: once the deployment has completed, connect to the URL , where is the public IP address of your VM (virtual machine). This URL is also sent to the email address you specified during deployment. Log in using the admin username and the password specified during deployment. Please note that the application uses a self-signed certificate; therefore, it is normal to receive a warning in your web browser the first time you connect to the application. You can safely trust this certificate after verifying its fingerprint, which is sent to you by email.
You can refer to the BeVyPN official website at https://www.bevypn.com/ for more information.
BeVyPN is a web application embedded in a dedicated network appliance called the CacheGuard Gateway. In addition to functioning as a VPN server, proxy, and firewall, the CacheGuard Gateway offers many other features, including an ad blocker and antivirus. To fully benefit from all the features provided by the CacheGuard Gateway, you can deploy a CacheGuard Gateway and then activate BeVyPN on it.
Caution: The BeVyPN offer on AWS is intended solely for evaluation or temporary use and is not designed for long-term deployment, as data transfer exceeding the specified monthly allowance is subject to additional charges imposed by AWS.
Highlights
- Become a VPN Provider.
- Easily & Quickly create VPN accounts for your Subscribers.
- Offer your Subscribers High Quality VPN, Proxy, Firewall and QoS.
Details
Introducing multi-product solutions
You can now purchase comprehensive solutions tailored to use cases and industries.
Features and programs
Financing for AWS Marketplace purchases
Pricing
Dimension | Cost/hour |
|---|---|
t3.micro | $0.02 |
t3a.micro | $0.02 |
t3a.small | $0.02 |
t3.small | $0.02 |
Vendor refund policy
Terminate your BeVyPN EC2 instance or delete your BeVyPN CloudFormation stack to stop paying your AWS resources consumption for BeVyPN.
How can we make this page better?
Legal
Vendor terms and conditions
Content disclaimer
Delivery details
BeVyPN 20 Subscribers
The BeVyPN application is based on a CacheGuard Gateway appliance. The CFT (Cloud Formation Template) allows you to properly deploy a CacheGuard Gateway and the BeVyPN application on AWS cloud.
To allow the BeVyPN application to work, its underlying CacheGuard Gateway requires 2 NIC (Network Interface Card). The two NIC are the internal (private) and the external (public) NIC. VPN clients connect to the external NIC and use the Web proxy that accept connections on the internal NIC. The CFT creates the two required NIC, connect them to two distinct sub networks and assigns to each NIC a private IP address. In addition, a public IP address is associated to the external NIC. All AWS resources are created in a dedicated VPC by default.
CloudFormation Template (CFT)
AWS CloudFormation templates are JSON or YAML-formatted text files that simplify provisioning and management on AWS. The templates describe the service or application architecture you want to deploy, and AWS CloudFormation uses those templates to provision and configure the required services (such as Amazon EC2 instances or Amazon RDS DB instances). The deployed application and associated resources are called a "stack."
Version release notes
The complete change logs can be found at https://cacheguard.net/doc/guide/changelogs.html
Additional details
Usage instructions
The application collects your name and email address and automatically send them in a secure way to CacheGuard Technologies Ltd. Your information is securely stored and will only be used to contact you in regards to the BeVyPN application.
Once the deployment has been finished, connect to the URL https://<public-ip-address> where <public-ip-address> is the public IP address of your VM (Virtual Machine). This URL is also sent to the email address that you specify during the deployment. Login as the "admin" username and the specified password during the deployment.
Please note that the application uses a self signed certificate, and it is therefore normal that you get a warning in your Web browser the first time you connect to the application. You can safely trust that certificate after having verified its fingerprint sent by email.
Resources
Vendor resources
Support
Vendor support
Offer your subscriber a High Quality VPN, Proxy, Firewall and QoS.
AWS infrastructure support
AWS Support is a one-on-one, fast-response support channel that is staffed 24x7x365 with experienced and technical support engineers. The service helps customers of all sizes and technical abilities to successfully utilize the products and features provided by Amazon Web Services.
