Cisco CSR1000V- Transit VPC with Transit Gateway

Cisco CSR1000V- Transit VPC with Transit Gateway

By: Cisco Systems, Inc. Latest Version: 17.3.4a

Product Overview

Bring Your Own License (BYOL) for CSR Transit VPC with Transit Gateway solution of the Cisco Cloud Services Router (CSR1000V) delivers maximum performance for virtual enterprise-class networking services in the AWS cloud. The CSR transit VPC serves as a global network transit center for connecting geographically dispersed VPCs and remote networks.

A CSR1000v pair is deployed in Transit VPC with VPN attachment to Transit Gateway (TGW) to provide VPN connectivity to various on-premise branch sites with greater control and functionality (QoS, Segmentation, encryption between the Transit VPC and branch sites, etc.). TGW is a regional network transit hub service provided by AWS to interconnect your VPCs in the same region in AWS cloud.

This solution uses lambda functions to first creates a Transit VPC and orchestrates two CSRs in this Transit VPC. Next it orchestrates a transit gateway, creates VPN connections with the CSRs and VPN attachment between CSRs and the transit gateway. The function then saves the VPN connection information to Amazon S3 bucket.

To activate this AMI, please obtain a license from Cisco with the following: (1) Tech Package: SEC or AX (2) Performance Level: 500 Mbps, 1 Gbps, 2.5 Gbps or 5Gbps and (3) Time period: 1-year, 3-year, or perpetual. The recommended instance types per throughput are: 500Mbps on c4.large, 1Gbps on c4.xlarge, 2.5Gbps on c4.2xlarge, 4.5Gbps on c4.4xlarge, and 5Gbps on c4.8xlarge. For AWS GovCloud region, please contact to obtain instructions on how to find CSR1000V.

When a CSR is spun up using this CFT there is a 30-day grace period to acquire a license for the newly deployed CSR. For a 60-day eval license, please follow the instructions at this link:
