Overview
The SEIL/x86 Ayame has dramatically improved performance and includes support for multicore CPUs, making it a central VPN router solution that can accommodate large, multi-node networks. Allocating CPU cores in virtual environments allows for improved processing performance, leading to high network node capacity. IIJ plans to implement support for multicloud administration, so SEIL/x86 Ayame will meet user needs as a gateway router that links corporate networks with several cloud platforms.
Highlights
- With support for 10 Gigabit Ethernet and multicore CPUs (up to eight cores), the software functions as a central router with the capacity for a large number of nodes.
Details
Features and programs
Financing for AWS Marketplace purchases
Pricing
Additional AWS infrastructure costs
Type | Cost |
|---|---|
EBS General Purpose SSD (gp3) volumes | $0.096/per GB/month of provisioned storage |
Vendor refund policy
SEIL/x86 Ayame BYOL utilizes licenses purchased from IIJ. Please contact your IIJ sales team or partner.
Legal
Vendor terms and conditions
Content disclaimer
Delivery details
64-bit (x86) Amazon Machine Image (AMI)
Amazon Machine Image (AMI)
An AMI is a virtual image that provides the information required to launch an instance. Amazon EC2 (Elastic Compute Cloud) instances are virtual servers on which you can run your applications and workloads, offering varying combinations of CPU, memory, storage, and networking resources. You can launch as many instances from as many different AMIs as you need.
Version release notes
Additional details
Usage instructions
Location of all sensitive information saved by customers
This product configuration information and BYOL license is saved on the AMI. The configuration information can be checked with the following command. 'show config' The BYOL license status can be checked with the following command. 'show key'
Explain all data encryption configuration
This product supports encryption user traffic via ssh, HTTPS and VPN.
SSH https://www.seil.jp/sx4/doc/sa/shell/sshd.html
HTTPS TLS version: 1.2 Web UI https://www.seil.jp/sx4/doc/sa/webui/webui.html
IPsec/IKE https://www.seil.jp/sx4/doc/sa/ipsec/detail.html
Remote Access Server (L2TP/IPsec, SSTP) SSTP: TLS version: 1.2 https://www.seil.jp/sx4/doc/sa/pppac/pppac.html
Step-by-step instructions for rotating programmatic system credentials and cryptographic keys.
SSH public key can be renewed with the following command. 'set sshd authorized-keys 0 pubkey <public key>'
Steps to verify the software is running on the AMI.
System information can be checked with the following command. 'show system' The status of each set function can be checked with the following command. 'show status <function>' See the technical manual for details on each command. https://www.seil.jp/sx4/doc/sa/toc/show.html
Step-by-step instructions for launch
- On the SEIL/x86 Ayame product page, click the 'Continue to Launch' button.
- Select latest revision and region, and click the 'Launch with EC2 Console' button.
- key pair: Create a new key pair or select an existing key pair.The private key downloaded at this time will be used later in the SSH connection.
- security group: Enabled 'Allow SSH traffic from' form Anywhere by default. Limit accepted networks if necessary.
- Click 'Launch Instance'.
- You can connect via SSH with the following command. 'ssh -i <key pair> admin@<IPaddress>'
- After connecting with SSH, enter the product key to use.
