MCM9000 [Private Offer]

MCM- Multi-Channel Monitoring Comprehensive, Integrated monitoring & visualization processing engine for video workflow MCM Is a processing engine that offers real-time decryption, probing, monitoring, and visualization of video content, along with advanced features like smart recording, penalty box, and much more. MCM ensures interoperability and compliance with industry standards and is JT-NM certified

• Monitoring | Probing: Fully integrated probing and monitoring | Receive-Monitor-Visualize all broadcast media formats | Error-detection, Alerting, Multi viewing tools | Mosaic outputs in HD / UHD video streams encoded/transmitted as ST 2110-20, 2022-6, standard h.264 / h.265 SPTS / MPTS and JPEGXS over Zixi and SRT protocols and parallel HLS output enable remote Multiviewing, mobile device access and flexible installation topology | Monitoring includes the full TR-101-290 suite and hundreds of their points of interest in content, encoding, transport, and metadata

-Audio: supports a broad range of industry-standard audio codecs, including PCM, AES 67, MPEG2, AAC, HE-AAC, A52 (AC3, E-AC3), Dolby E, and Dolby Atmos. The platform performs real-time detection of a variety of audio anomalies, such as:

• No audio or silence (down to specific channels like left, right, or surround)

• Phase and true-peak level errors

• Loudness issues, including short-term loudness monitoring

• Bitrate inconsistencies _ Codec/channel mismatches, mono audio detection, and language descriptor discrepancies This functionality ensures consistent audio integrity across all monitored streams.

• Visualization | Multiviewer: Fully integrated Multiviewing tool | Advanced Layout Editor | User-defined, flexible layouts (up to 100 tiles/layout) | Mix / Match uncompressed and compressed signals | ST 2110 Ultra-low latency combined with high input/output density per server | Full Tally / UMD integration | JPEG-XS inputs for cloud-enabled / large-scale monitoring | Built-in redundancy for ST 2022-7 inputs/outputs two separate NIC deployments).

• Realtime Decryption: Proven and secure method of real-time Decryption, Monitoring, and Viewing of encrypted content provides full monitoring and visualization. Utilizing a direct and secure relationship with the encryption key management server, the MCM fully decodes, monitors, and displays the content seamlessly, enabling assurance that the Protected content is being delivered reliably throughout the ecosystem.

• Smart Recording (Streams, OTT): Performs a continuous background recording on each source, enabling full-event recording of an error condition. When an error occurs, the MCM uses the pre-event recording and combining it with a recording of the event duration, with a post-event tail to provide a full view of the event occurrence. This recording can be delivered to external storage for later review.

• Penalty Box: Centralized Error Display | Unlimited Independent Penalty Boxes | Penalty Box placements in any layout.
