The instance must have two network adapters in the launch configuration

• Name the first (primary) adapter 'MGMT'. This will used as the primary network adapter used to access the instance. After launching the instance, you will need to assign an Elastic IP to this adapter to access the instance using RDP.
• Name the second adapter 'CAPTURE'. This will be used to receive mirrored traffic for analysis. This adapter will not have an IP stack enabled on it. Set the root volume to the following:
• Gp2
• 300 GiB
• Delete on termination Launch the instance Create an Elastic IP and assign it to the primary network adapter named MGMT. Connect to the instance using Windows Remote Desktop using the following default login credentials:
• Username: Administrator
• You can obtain the default password from the AWS RDP Client Connect Page
• Note: You can change these credentials after your first login. To run Observer, double-click the Observer desktop icon. Select one of the two Demo modes on the initial splash screen. Select the File menu item then click the 'License Observer' icon. In the license dialog, enter the license number provided to you from VIAVI Solutions and click the 'Enter Name' button. Enter your Contact and Company information provided to you from VIAVI Solutions and click the 'OK' button. In the confirmation screen, click the Accept button. In the licensing dialog, click the OK button. If properly licensed, you should see confirmation that the license was accepted Restart the instance
• On first start up of the instance, the network adapters are renamed 'MGMT' and 'CAPTURE'. For Observer to see these new names, a restart is necessary.
